Eye Speed® I/O
Eye Speed® I/O
Rugged high speed cable systems feature a positive latching system and support multiple protocols.
FEATURES
- Small form factor for space saving applications
- Micro rugged latching system
- Shielded housing for EMI protection or sealed cable for IP68 applications
- Supports SAS, SATA, Fibre Channel, Ethernet, PCIe® and InfiniBand™ protocols
- High reliability Edge Rate® contacts
EPLSP
0.80 mm Eye Speed® I/O Rugged Latching High-Speed Cable Assembly
Features
- Supports SAS, SATA, Fibre Channel, Ethernet, PCIe® and InfiniBand™ protocols
- High-cycle Edge Rate® contact system
- Rugged positive latch
- 32 AWG low skew pair twinax cable
- Available in 19 and 31 positions
- Small 25.40 mm bend radius high flex cable
ERI8
0.80 mm Eye Speed® I/O Right-Angle Edge Rate® Receptacle
Features
- Rugged Edge Rate® contact system
- Low profile right-angle design
- Standard alignment pins and surface mount tails
- Selective gold plated contacts
- Available in 19 and 31 positions
- Optional tape and reel packaging
ERC
Cage for ERI8/EPLSP Series Eye Speed® I/O High-Speed System
Features
- Rugged die Cast, screw down design
- Low profile right-angle design
- Available with and without panel gasket
- Available in 19 and 31 positions
RCH
0.80 mm Eye Speed® Sealed IP68 High-Speed I/O Cable System
Features
- Supports SAS, SATA, Fibre Channel, Ethernet, PCIe® and InfiniBand™ protocols
- IP68 sealed system
- Rugged overmold construction with positive latches
- Rugged Edge Rate® contact system
- Small 25.40 mm (1.00") cable bend radius
- 100 ohm differential signal routing
RPBH
Cage For RCH/ERI8 Series, Eye Speed® Sealed IP68 High-Speed I/O System
Features
- Rugged die cast panel mount design
- Low profile right-angle
- Supplied with panel mount hardware
- Available in 19 positions
- Dust cap available
