Industrial Applications
High-Performance & Rugged Solutions
Intelligent automation continues to change the way processes and information are managed, driving advancements like machine learning, sensors, and computing power to fuel integration.
Samtec's high-performance and rugged solutions combined with exceptional Sudden Service® support the spectrum of industrial applications producing unprecedented efficiency and quality in the market today.
Rugged Tiger Eye™ SystemsRugged, High-Speed, High Reliability Connector, Tiger Eye™ Systems
This rugged, high cycle, high reliability connector system features Samtec's Tiger Eye™ contact system.
Features
- High-reliability Tiger Eye™ three-finger BeCu contact system
- Optional locking and latching systems for higher withdrawal force
- Extended Life Product™ testing available
- Standard and cost-saving designs
URSA® I/OURSA® I/O Ultra Rugged Power Cable System
URSA® I/O features a hyperboloid-type contact for extreme reliability and high mating cycles in ultra rugged applications with EMI protection.
Features
- Four points of contact for an extremely reliable connection
- Hyperboloid-type contact for extreme high mating cycles
- Micro 1.00 mm pitch in double row space saving design
- Extreme density with up to 1,450 total I/Os in a 1RU panel (29 cables at 50 total I/Os each)
- Cable-to-cable and cable-to-board solutions
- EMI shielding to limit signal degradation and optimize performance
AcceleRate® mPAcceleRate® mP High-Density, High-Speed Power/Signal Arrays
These 0.635 mm pitch power/signal arrays achieve 64 Gbps PAM4 speeds and feature rotated power blades for 22 Amps/blade and simplified breakout region (BOR). View the full line of AcceleRate® products.
Features
- Best in class density for power and signal
- Power blades rotated 90º gives equal access to heat escape for uniform cooling, increased current capacity and reduced crowding
- Supports 64 Gbps PAM4 (32 Gbps NRZ) applications
- PCIe® 6.0/CXL® 3.1 capable
- Up to 22 Amps per power blade
- Open-pin-field for grounding and routing flexibility
- High-density multi-row design
- Low profile 5 mm stack height; up to 16 mm in development
- 4 or 8 total power blades; up to 10 in development
- 60 or 240 total signal positions; additional position counts in development
- 0.635 mm signal pitch
- Optional alignment pins and weld tabs for a secure connection to the board
- Polarized guide posts for blind mating
- View the full line of AcceleRate® products
Micro Blade & BeamMicro Blade & Beam Ultra Fine Pitch Connectors
0.40 mm and 0.50 mm pitch Micro Blade & Beam ultra slim, ultra low profile connectors.
Features
- Ultra fine pitch – 0.40 mm and 0.50 mm
- Ultra low stack down to 2.00 mm
- Slim body design for increased board space savings
Flyover® Cable Technology Flyover® Cable Technology
Flyover® Twinax Cable Assemblies
Features
- Achieve next gen speeds by routing signals via ultra low skew twinax cable versus through lossy PCB
- Cost-effective, high-performance and heat efficient answer to the challenges of 56 Gbps bandwidths and beyond
- Ideal for 28 – 112+ Gbps applications
- Features Samtec’s proprietary co-extruded Eye Speed® twinax cable technology
- Simplifies board layout, extends signal reach and density
- Thermal improvement versus a standard network switch
Precision RF Precision RF
Microwave/Millimeter Wave Cable Assemblies & Connectors
Features
- High-frequency, microwave/millimeter wave solutions to 110 GHz
- Cable assemblies, cable connectors and board level connectors
- Variety of interfaces: 1.00 mm, 1.35 mm, 1.85 mm, 2.40 mm, 2.92 mm, 3.50 mm, SSMA, SMP, SMPM, ganged SMPM, SMA, N Type, TNCA
- Magnum RF™ ganged SMPM for 40% greater density, less processing time and better positional alignment
- Low-loss microwave and millimeter wave cable from .047" to .277"
- Vertical or edge launch solderless compression mount board connectors for test and measurement applications
- Soldered push-on board connectors for high-density, blind-mate applications
- Between-series and in-series adaptors designed for well-performing VSWR
AcceleRate® MiniAcceleRate® Mini Extreme Performance, Mini Form Factor Cable System
AcceleRate® Mini Flyover® system delivers 112 Gbps PAM4 performance in an incredibly small form factor via Eye Speed® Thinax™ ultra performance twinax cable.
Features
- 112 Gbps PAM4 performance
- Eye Speed® 34 AWG, 92 Ω Thinax™ ultra performance twinax cable
- One or two differential pairs
- Vertical and right-angle mating board connector
- Design flexibility as an End 2 option for Flyover® assemblies
- Friction retention latching for a secure connection
- Standard alignment pins
- View the full line of AcceleRate® products
