1.00 mm Pitch Micro Mate™ Discrete Wire System
1.00 mm Pitch Micro Mate™ Discrete Wire System
FEATURES
- One product family that supports cable-to-board, cable-to-cable and cable-to-panel applications
- Extremely small form factor compared to other 28 AWG assemblies
- Rugged single or double row latching for a solid connection
- Panel mount version fits .033” - .090” panel thickness
- Teflon™ fluoropolymer wire available for high temp or halogen free applications
- Extremely low profile, right-angle board mount connector/cable mate
- Available as components or complete assemblies
- Assembly tooling available
S1SS
Micro Mate™ Single Row Discrete Wire Cable Assembly, 1.00 mm Pitch
Features
- 1.00 mm (.0394") pitch
- Crimp-style dual leaf contact
- 2, 3, 5, 7, 10, 15 and 20 contacts
- 28 or 30 AWG
S1SST
Micro Mate™ Single Row Discrete Wire Cable Assembly, Teflon™ Fluoropolymer Wire, 1.00 mm Pitch
Features
- 1.00 mm (.0394") pitch
- Crimp-style dual leaf contact
- 2, 3, 5, 7, 10, 15 and 20 contacts
- 28 or 30 (Preliminary) AWG Teflon™ fluoropolymer
S1SD
Micro Mate™ Double Row Discrete Wire Cable Assembly, 1.00 mm Pitch
Features
- 1.00 mm (.0394") pitch
- Crimp-style dual leaf contact
- 2 through 20 contacts per row
- 28 and 30 AWG cable
- UL: File # E111594
S1SDT
Micro Mate® Double Row Discrete Wire Cable Assembly, Teflon™ Fluoropolymer Wire, 1.00 mm Pitch
Features
- 1.00 mm (.0394") pitch
- Crimp-style dual leaf contact
- 2 through 20 contacts per row
- 28 and 30 AWG Teflon™ fluoropolymer cable
T1M
Discrete Wire Terminal Strip, 1.00 mm Pitch
Features
- 1.00 mm (.0394") pitch
- Vertical and horizontal surface mount
- 2, 3, 5, 7, 10, 15 and 20 contacts
T1SS
1.00 mm Micro Mate™ Single Row Discrete Wire Cable Assembly, Terminal
Features
- 28 or 30 AWG wire
- 2 – 10 positions
- Choice of single ended, double ended or transfer end
T1SST
1.00 mm Micro Mate™ Single Row Discrete Wire Cable Assembly, Teflon™ Fluoropolymer Wire, Terminal
Features
- 28 or 30 (Preliminary) AWG Teflon™ fluoropolymer
- 2 – 10 positions
- Choice of single ended, double ended or transfer end
T1SD
1.00 mm Micro Mate™ Double Row Discrete Wire Cable Assembly, Terminal
Features
- 28 or 30 AWG wire
- 2 – 10 positions per row
- Choice of single ended, double ended or transfer end
T1SDT
1.00 mm Micro Mate™ Double Row Discrete Wire Cable Assembly, Teflon™ Fluoropolymer Wire, Terminal
Features
- 28 or 30 (Preliminary) AWG Teflon™ fluoropolymer
- 2 – 10 positions per row
- Choice of single ended, double ended or transfer end
T1PS
1.00 mm Micro Mate™ Single Row Panel Mount Discrete Wire Cable Assembly, Terminal
Features
- 28 or 30 AWG wire
- 3 – 10 positions
- Fits .033” (0.84 mm), .062” (1.57 mm) and .090” (2.29 mm) thick panels
- Choice of single ended, double ended or transfer end
T1PST
1.00 mm Micro Mate™ Single Row Panel Mount Discrete Wire Cable Assembly, Teflon™ Fluoropolymer Wire, Terminal
Features
- 28 or 30 (Preliminary) AWG Teflon™ fluoropolymer
- 3 – 10 positions
- Fits .033” (0.84 mm), .062” (1.57 mm) and .090” (2.29 mm) thick panels
- Choice of single ended, double ended or transfer end
T1PD
1.00 mm Micro Mate™ Double Row Panel Mount Discrete Wire Cable Assembly, Terminal
Features
- 28 or 30 AWG wire
- 2 – 10 positions per row
- Fits .033” (0.84 mm), .062” (1.57 mm) and .090” (2.29 mm) thick panels
- Choice of single ended, double ended or transfer end
T1PDT
1.00 mm Micro Mate™ Double Row Panel Mount Discrete Wire Cable Assembly, Teflon™ Fluoropolymer Wire, Terminal
Features
- 28 or 30 (Preliminary) AWG Teflon™ fluoropolymer
- 2 – 10 positions per row
- Fits .033” (0.84 mm), .062” (1.57 mm) and .090” (2.29 mm) thick panels
- Choice of single ended, double ended or transfer end
ISS1
1.00 mm Micro Mate™ Single Row Discrete Wire Cable Assembly Housing
Features
- 1.00 mm (.0394") pitch
- Semi-auto assembly tooling available
- Hand tool available
- 2, 3, 5, 7, 10, 15 and 20 contacts
ISD1
1.00 mm Micro Mate™ Double Row Discrete Wire Cable Assembly Housing
Features
- 1.00 mm (.0394") pitch
- Semi-auto assembly tooling available
- Hand tool available
- 2 through 20 contacts per row
CC09R
1.00 mm Pitch Micro Mate™ Crimp Contact, Reel Packaging
Features
- 1.00 mm (.0394") pitch
- Crimp-style dual leaf contact
- Assembly tooling available (Visit samtec.com/tooling)
- Reeled contacts (30k reel)
CC09M
1.00 mm Pitch Micro Mate™ Crimp Contact, Mini Reel Packaging
Features
- 1.00 mm (.0394") pitch
- Crimp-style dual leaf contact
- Assembly tooling available (Visit samtec.com/tooling)
- Reeled contacts (5k reel)
IST1
1.00 mm Micro Mate™ Single Row Discrete Wire Cable Assembly Housing, Terminal
Features
- 1.00 mm (.0394") pitch
- Semi-auto assembly tooling available
- Hand tool available
- 2 – 10 positions
ISP1
1.00 mm Micro Mate™ Single Row Panel Mount Discrete Wire Cable Assembly Housing, Terminal
Features
- 1.00 mm (.0394") pitch
- Semi-auto assembly tooling available
- Hand tool available
- 3 – 10 positions
- Fits .033” (0.84 mm), .062” (1.57 mm) and .090” (2.29 mm) thick panels
IDT1
1.00 mm Micro Mate™ Double Row Discrete Wire Cable Assembly Housing, Terminal
Features
- 1.00 mm (.0394") pitch
- Semi-auto assembly tooling available
- Hand tool available
- 2 – 10 positions
IDP1
Micro Mate™ Discrete Wire Socket Housing, 1.00 mm Pitch
Features
- 1.00 mm (.0394") pitch
- Semi-auto assembly tooling available
- Hand tool available
- 2 – 10 positions
- Fits .033” (0.84 mm), .062” (1.57 mm) and .090” (2.29 mm) thick panels
TC37M
1.00 mm Micro Mate™ Crimp Terminal, Mini Reel Packaging
Features
- 1.00 mm (.0394") pitch
- Assembly tooling available
- Reeled contacts (5k reel)
TC37R
1.00 mm Micro Mate™ Crimp Terminal, Full Reel Packaging
Features
- 1.00 mm (.0394") pitch
- Assembly tooling available
- Reeled contacts (25k reel)
