Samtec 0.80 mm pitch Edge Rate® Differential Pair High-Speed Edge Card Connectors offer 56 Gbps PAM4 performance in typical edge card applications. The HSEC8-DP SI Evaluation Kit provides system designers and SI engineers an easy-to-use solution for testing HSEC8-DP connectors.

The HSEC8-DP SI Evaluation Kit delivers a high-quality system with robust mechanical design. It can be used standalone for HSEC8-DP connectors. Please contact Samtec’s technical experts at [email protected] for additional information.

• Two PCB system with compact form factor
• One PCB contains HSEC8-DP connector (HSEC8-120-01-L-DP-A-WK-K)
• Second PCB contains 0.80 mm pitch card edges that mate with HSEC8-DP connector
• Routes high-speed differential pairs (8 total) from HSEC8-DP connectors and card edges to high-precision RF connectors
• Supports multiple high-precision RF connector options (2.4 mm/2.92 mm SMAs)
• Optimized SI performance via Samtec Final Inch® BOR PCB trace routing
• Enable time domain measurements via direct connection to TDR/TDTs
• Enable frequency domain measurements via direct connection to VNAs
